Y系列电动机主要技术参数

型号项目	功率    Kw	电压  V	防护 等级	频率    Hz	接法	转速  r∕min	噪声  db(A)	重量  kg
Y801-2	0.8	380	IP44	50	Y	2800	66	17
Y90S-4	1.1	380	IP44	50	Y	1400	67	18
Y90L-4	1.5	380	IP44	50	Y	1400	62	25
Y90L-2	2.2	380	IP44	50	Y	2840	67	23
YSH90L-2	2.2	380	IP44	50	Y	2880	67	23
Y100L2-4	3.0	380	IP44	50	Y	1420	70	31
Y100L-2	3.0	380	IP44	50	Y	2880	75	29
YSH90L2-2	3.0	380	IP44	50	Y	2880	75	27
Y112M-2	4.0	380	IP44	50	△	2890	74	42
Y112M-4	4.0	380	IP44	50	△	1440	68	51
Y132S-4	5.5	380	IP44	50	△	1440	78	69
Y132M-4	7.5	380	IP44	50	△	1440	68	81
Y132M2-4	9.0	380	IP44	50	△	1440	70	88

Y系列电动机的基本防护等级为IP44，绝缘等级为B级， 具有设计新意、造型美观、效率高、噪声低、转矩高、起动性能好、结构紧凑、使用维护方便等优点，该系列电动机漆包铜线全部按照国家标准要求的线径和圈数生产。

The basic protection level of Y series motor is IP44, insulation class is B, which has advantages of innovated designation, elegant appearance, high efficiency, low noise, high torque, high starting performance, compact structure and easy maintenance etc.. This series of electric motor copper coil is manufactured according to the national standard.
